Printing Protection / Mobile BOPP Lamination Film Roll SGS ISO9001 Certification
Glossy Specifications:
|
TYPE
|
THICKNESS (micron)
|
|
GLOSSY
|
TOTAL
|
BASE
|
EVA
|
|
17
|
12
|
5
|
|
18
|
12
|
6
|
|
20
|
12
|
8
|
|
22
|
12
|
10
|
|
23
|
15
|
8
|
|
25
|
15
|
10
|
|
27
|
15
|
12
|
|
30
|
15
|
15
|
|
42
|
28
|
14
|
|
WIDTH (mm)
|
200 ~ 2210
|
|
LENGTH (m)
|
100 ~ 8000
|
|
PAPER CORE
|
25.4mm(1 inch) / 76mm (3 inch)
|
|
BONDING
|
≤2
|
|
CORONA TREATED
|
Double side
|
|
SURFACE TENSION
|
38 Dyne/cm ≤ 42 Dyne/cm
|
|
LAMINATION TEMP.
|
90±10°C
|
|
ROLLER PRESSURE
|
10 ~ 20Mpa
|
|
LAMINATION SPEED
|
20 ~ 70M
|
Description:
The surface of the hot bonded film is extruded with low temperature molten resin, and the film is bonded into paper products by heating and pressure. A variety of surface finishes can add value to printed surfaces. The glossy BOPP thermal lamination film provides a shiny colored finish. Its use can improve the appearance and service life of laminating machine.
Good performance characteristics and low price make BOPP Thermal composite film ideal for all kinds of printed and non-printed paper and board, including book covers, cosmetic packaging, magazines, documents, shopping bags, diaries, maps and more.
The Advantages NEI BOPP thermal lamination film VS cold laminating film
1. Environmentally friendly
2. Safe operation
3. Excellent performance
4. Easy handling
5. High efficiency
6. Wide adaptability
Why chooses NEI?
1. NEI has professional experience in the film industry since 1995, so we have good quality control and after-sales service to support you.
2. 10 years of experience in exporting to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc., so we have a good reputation in these fields.
3. Compared with other thermal composite films, our EVA glue is 100% imported from Korea, which guarantees the adhesion of our films.
4. Customize size and thickness according to customer requirements. Labels can also be customized.
5. Fast production and delivery.
Special Instruction:
1. It is recommended to laminate NEI gloss BOPP thermal laminating film under roller temperature range of 85 to 110°C and roller pressing of 10 to 20Mpa. However, the optimal conditions depend on the speed and dimensional stability of the selected laminator.
2. It is recommended that the printed surface be sufficiently dried before lamination and that one surface be sufficiently cooled before laminating to other surfaces.
